The DynaBolt Plus Sleeve Anchor is a medium-duty, torque-controlled expansion anchor with an integrated pull-down section, designed for anchoring timber and steel fixtures to concrete, brick or block. It is available in a variety of head styles and finishes.
- Patented expansion sleeve closes gaps of up to 5mm, pulling down on the fixture to induce clamp load
- Fully assembled through-fixture anchor – no separate parts to lose on site
- Eliminates assembly, marking-out and re-positioning steps for fast, easy installation
- Multiple head styles (hex nut, hex bolt, countersunk/flat, round) suit a wide range of applications
Specifications
- Anchor size: M10
- Anchor length: 49mm
- Drilled hole diameter: 10mm
- Minimum hole depth: 55mm
- Max fixture thickness: 20mm
- Effective length: 42mm
- Fixture hole: 12mm
- Finish: Hot-dip galvanised, hex nut
