BFT Giuno Ultra BT A20
SKU: 2600869
$905.00
In stock
Pay with
BFT Giuno Ultra BT A20
$905.00
$905.00
Hydraulic operator with 24 V for hinged wings up to 2 m. 300 kg in weight and use very intensive. Manoeuvre time 14 s.
Main Features
- Selectable block system: the operators can be converted to reversible, with opening block, closing block or double block. All this by simply turning a key.
- New magnetic limit switch: together with D-Track technology, offers extreme precision of maneuver and positioning. Double sensor system to define in detail end of the maneuver slowdowns. High reliability against dust, water and ice.
- Control unit with display and new, simplified scenario-based programming.
Specifications
| Max. weight of door/gate wing | 300 kg |
| Frequency of use | very intensive |
| Useful rod stroke | 270 mm |
| Protection rating | IP55 |
| Maximum angle | 110 ° |
| Environmental conditions | -20 ÷ 60 °C |
| Cycle time | 14 s |
| Interconnectivity | no |
| Control unit | THALIA P |
| Type of limit switch | Magnetic |
| Board power supply | 230 V |
| Slowdown | Yes |
| Motor voltage | 24 V |
| Locking | Selectable in opening/closing |
| Power consumption | 90 W |
| Release | Triangle key |
| Max. width of door/gate wing | 2 m |
| Impact reaction | D-Track |
| Reference | P935105 |
| Part number | 2600869 |
Documents
- Document (678653) (2600869_manual_678653.pdf)
- Document (708902) (2600869_manual_708902.pdf)
- Document (708903) (2600869_manual_708903.pdf)
- Document (701109) (2600869_manual_701109.pdf)
- Document (701108) (2600869_manual_701108.pdf)
- BFT Technical Download (P935105)
Description
Hydraulic operator with 24 V for hinged wings up to 2 m. 300 kg in weight and use very intensive. Manoeuvre time 14 s.
Main Features
- Selectable block system: the operators can be converted to reversible, with opening block, closing block or double block. All this by simply turning a key.
- New magnetic limit switch: together with D-Track technology, offers extreme precision of maneuver and positioning. Double sensor system to define in detail end of the maneuver slowdowns. High reliability against dust, water and ice.
- Control unit with display and new, simplified scenario-based programming.
Specifications
| Max. weight of door/gate wing | 300 kg |
| Frequency of use | very intensive |
| Useful rod stroke | 270 mm |
| Protection rating | IP55 |
| Maximum angle | 110 ° |
| Environmental conditions | -20 ÷ 60 °C |
| Cycle time | 14 s |
| Interconnectivity | no |
| Control unit | THALIA P |
| Type of limit switch | Magnetic |
| Board power supply | 230 V |
| Slowdown | Yes |
| Motor voltage | 24 V |
| Locking | Selectable in opening/closing |
| Power consumption | 90 W |
| Release | Triangle key |
| Max. width of door/gate wing | 2 m |
| Impact reaction | D-Track |
| Reference | P935105 |
| Part number | 2600869 |
Documents
- Document (678653) (2600869_manual_678653.pdf)
- Document (708902) (2600869_manual_708902.pdf)
- Document (708903) (2600869_manual_708903.pdf)
- Document (701109) (2600869_manual_701109.pdf)
- Document (701108) (2600869_manual_701108.pdf)
- BFT Technical Download (P935105)
