DEA STING/S SHOWROOM

DEA STING/S Showroom (625499) is a sectioned cutaway of the STING electromechanical operator, made for showroom display. The operator is cut open so the internal mechanism can be seen. It is not a working gate motor and is not for installation.

The working STING range automates residential and apartment-complex swing gates, with leaves up to 3 metres long and up to 400 kg, and an opening of up to 110°. The body is a monoblock casting with metal gears and aluminium and steel external parts. Adjustable screw-on fixing plates (MLS/SFR) suit different column sizes. Optional mechanical stops (MAC/FM) stop the leaf without ground stops. A metal key releases the operator for manual opening if the power fails.

Main features

• Sectioned STING operator for showroom display
• Cutaway body so the internal mechanism is visible
• Not a working operator — not for gate installation
• Represents the STING swing-gate operator family

What the STING range is for

• Residential and apartment-complex swing gates
• Leaves up to 3 m and up to 400 kg (working models)
• Opening up to 110°
• Adjustable screw-on fixing plates included on working STING operators
• Optional mechanical stops so ground stops are not required
• Manual release with the supplied metal key
• Working versions in 230 V and 24 V, including encoder, BOOST and reversible models
