Trio Australia Hinge, Light Duty, Adjustable Tension 20kg (Pair) DPH120
See more by Deadlocks & Latches

Trio Australia Hinge, Light Duty, Adjustable Tension 20kg (Pair) DPH120

SKU: DPH120
: 9328879107035

$33.00

In stock
Trio Australia Hinge, Light Duty, Adjustable Tension 20kg (Pair) DPH120

$33.00

$33.00

Economy Self-Closing Hinge in black polymer, supplied as a pair. Self-closes gates up to 20kg per pair.

Key Features

  • Supplied as a matched pair
  • Impact-resistant black polymer – anti-rust, unaffected by moisture
  • Slotted leaves allow vertical adjustment during installation
  • Symmetrical holes let the hinge be inverted to suit left- or right-hand gates
  • Adjustable spring tension via the supplied adjustor key
  • The self-closing hinge supplied in Trio's DPK1200MK3 gate kit

Technical Specifications

Finish Black
Range SafeAZ safety gate hardware
Material Polymer (Trio does not publish the polymer type)
Compliance Trio's published wording for the SafeAZ range is: “Trio Safety Products function well, are easy to install, durable and comply with the strict safety standards for both here in Australia and in New Zealand.” Trio does not name AS 1926.1 or any specific standard for this product, and publishes no certification. Verify current pool-barrier requirements with your local authority before specifying.
Care Inspect annually, or more often with heavy use. Do not use petroleum-based lubricants – lubricate with powdered graphite only. Keep free of sand, ice and dust.
Weight / packed dimensions Not published
Trio product name Economy Self-Closing Hinge
Self-closing capacity Self-closes gates up to 20kg per pair.
Tension adjustment Adjustable, using the supplied adjustor key: rotate the key to free the spring tension fixing pin, move the pin one hole, then rotate back. Adjust one pin position, one hinge at a time.
Mounting style Alignment legs that screw-fix to the sides of the fence and gate posts
Maximum gate load Not published – Trio publishes a self-closing capacity only
Supplied as Pair
Mounting positions Top edge of the upper hinge within 100mm of the top surface of the top rail; bottom surface of the lower hinge within 100mm of the lower rail.
Barcode / EAN 9328879107035
Description

Economy Self-Closing Hinge in black polymer, supplied as a pair. Self-closes gates up to 20kg per pair.

Key Features

  • Supplied as a matched pair
  • Impact-resistant black polymer – anti-rust, unaffected by moisture
  • Slotted leaves allow vertical adjustment during installation
  • Symmetrical holes let the hinge be inverted to suit left- or right-hand gates
  • Adjustable spring tension via the supplied adjustor key
  • The self-closing hinge supplied in Trio's DPK1200MK3 gate kit

Technical Specifications

Finish Black
Range SafeAZ safety gate hardware
Material Polymer (Trio does not publish the polymer type)
Compliance Trio's published wording for the SafeAZ range is: “Trio Safety Products function well, are easy to install, durable and comply with the strict safety standards for both here in Australia and in New Zealand.” Trio does not name AS 1926.1 or any specific standard for this product, and publishes no certification. Verify current pool-barrier requirements with your local authority before specifying.
Care Inspect annually, or more often with heavy use. Do not use petroleum-based lubricants – lubricate with powdered graphite only. Keep free of sand, ice and dust.
Weight / packed dimensions Not published
Trio product name Economy Self-Closing Hinge
Self-closing capacity Self-closes gates up to 20kg per pair.
Tension adjustment Adjustable, using the supplied adjustor key: rotate the key to free the spring tension fixing pin, move the pin one hole, then rotate back. Adjust one pin position, one hinge at a time.
Mounting style Alignment legs that screw-fix to the sides of the fence and gate posts
Maximum gate load Not published – Trio publishes a self-closing capacity only
Supplied as Pair
Mounting positions Top edge of the upper hinge within 100mm of the top surface of the top rail; bottom surface of the lower hinge within 100mm of the lower rail.
Barcode / EAN 9328879107035
