Vespol Finio 350mm x 5m Grey 16657

Ubiflex Finio waterproof flashing. Includes adhesive strips. Lightweight. Installation temperature from −10°C to 50°C.

Product Features

• Suitable for all flashing applications
• Remains strong & durable in a wide temperature range
• Does not soften or become brittle due to harsh weather
• Good wind uplift resistance

Installation Benefits

• Quicker installation than other flashing products
• Easy to dress into shape by hand and bossing tools
• Easy to cut with scissors or knife
• No health risks such as lead exposure
• Can be installed in long lengths without expansion joints

Technical Data

• Operating temperature range: −30°C to +140°C
• Installation temperature range: −10°C to +50°C
• Designed and manufactured in accordance with AS/NZS 2904:1995 – damp-proof courses and flashings
• Tested in accordance with AS/NZS 4347.1 determination of water permeability, AS/NZS 4347.3 pliability and AS/NZS 4347.6 falling dart impact
• Tested in accordance with AS/NZS 4020:2018 – testing of products for use in contact of drinking water
• UV resistant after exposure at 3000 hours UV-B
• Application: flashings and damp-proof courses
• Classification: Exposed
• Certified as complying under the ISO 9001 Certification Scheme and audited by Lloyds Register LRQA
• Roll sizes: 300mm × 5m, 350mm × 5m, 600mm × 5m

Installation Guidelines

• Finio can be installed in 5m lengths.
• Ensure that the area for installation is clean, dry and dust free.
• Firstly, form Finio to the basic shape required for installation whilst keeping the release liner in place as this protects the adhesive strips.
• Remove the upper part of the release liner whilst pressing Finio and the upper adhesive strip into the required position.
• Finio must always be “chased” or “built into” brickwork or “over-flashed”.
• Dress Finio into the profile of the roofing material using your hands or dressing tool with the lower release liner in place.
• The release liner should be kept on as long as possible to keep the adhesive strip clean.
• Lift the bottom edge of Finio to remove the lower part of the release liner whilst firmly sticking down the lower adhesive strip to the roofing material.
• Finio must be firmly and neatly dressed onto the roofing material it covers so that there are no air gaps or cavities beneath it.
• Following installation Finio should be protected until all building work such as rendering or painting is completed.
• Always clean mortar, concrete and paint materials from the surface of Finio immediately.
• Finio should be installed vertically for step flashings with a horizontal Finio soaker. Abutment flashings should also be installed horizontally.
• Overlapping / Joining – Finio should be overlapped by 50mm on all joints. Pressure should be applied by hand or with a dressing tool to achieve a good seal. The pieces will permanently bond together.

Notes

• Test any chemical agents on Finio before use.
• Don’t walk on Finio during installation.
• Although the release liner should be left in place as long as possible to ensure that the adhesive strips remain clean, it must be removed during installation.
